4D imaging radar

· 2 x 24CH transmitter chips, 4 x 12CH receiver chips
· Superior performance in terms of channel isolation, noise figure, and transmit power
· Integrated Radar Processing Unit (RPU) architecture and embedded radar signal processing algorithms
· Modular design, customizable resolution, range, FOV, and functions

Front radar（4T4R）

· Detection distance of more than 300m
· The azimuth angle resolution is less than 1.5°
· Waveguide antenna with wide beamwidth and high efficiency
· The waveguide antenna is not on the same side as the chips, does not occupy the PCB area, and reduces the volume

Front radar（8T8R）

· Pulse-compressed waveform technology with variable center frequency enables high range resolution for long-range detection
· Neural network algorithms enhance detection accuracy and point cloud quality in DOA and target processing
· The waveguide antenna design delivers long-range, high-resolution performance with a wide field of view, optimized for cost-effective mass production

Corner radar

· 4T4R, High-accuracy horizontal angle measurement and better elevation measurement ability
· Anti-jamming, occlusion detection, self-calibration, target classification, road edge recognition, etc
· ASILB, Support information security FULL EVITA
· Selectable output (CANFD) point cloud (350 points), target, function

In-cabin radar

· Cost-effective domestic solution
· Automotive electronics development process（AUTOSAR、Functional safety、ASPICE）
· Robust manufacturing and supply chain assurance
· Contactless, privacy-protecting, unaffected by light

Barrier gate radar

· About 4G working bandwidth, distance resolution 0.05m
· AiP package, PCB with low-cost FR4
· AiP package, the antenna does not occupy the PCB area, reducing the size

Traffic radar
